BOILER BOOK CFC-E DIMENSIONS AND RATINGS
11
Table 2. Dimensions (Metric) Model CFC-E
ITEM DIMENSIONS (mm) 500 750 1000 1500 2000
A Overall Height 1982 1982 1982 2028 2028
B Overall Width 886 886 886 908 908
C Overall Depth 1255 1255 1255 1422 1422
D Width Less Casing 816 816 816 838 838
E Gas Connection to Floor 1786 1786 1786 1877 1877
F Side of Casing to Gas Connection 95 95 95 180 180
G Side of Casing to Air Inlet 275 275 275 273 273
H Top of Casing to Air Inlet 196 196 196 180 180
J Floor to Condensate Drain 160 160 160 160 160
K Floor to Bottom of Casing 279 279 279 279 279
L Side of Base to Flue Outlet 189 189 189 217 217
M Side of Base to Flue Outlet (Offset) 164 164 164 192 192
N Rear of Base to Flue Outlet 165 165 165 190 190
P Casing Depth 921 921 921 1077 1077
Q Casing Height 1703 1703 1703 1749 1749
R Floor to Lower Return Connection 428 428 428 428 428
S Floor to Upper Return Connection 808 808 808 808 808
T Floor to Supply Connection 1511 1511 1511 1511 1511
U Floor to Air vent Connection 1683 1683 1683 1683 1683
V Air Vent Line Projection From Rear of Casing 81 81 81 84 84
FORK POCKETS (mm)
LL Pocket Height 100 100 100 100 100
MM Pocket Width 300 300 300 300 300
NN Overall Pocket Width 700 700 700 700 700
WEIGHTS
Dry Weight (kg) 589 589 633 844 926
Shipping Weight (kg) 641 641 686 901 983
Operating Weight (kg) 939 939 969 1260 1280
Water Volume (liter) 350 350 324 416 370
CLEARANCES (mm)
Notes:
• Boiler rear must be accessible for servicing.
• Side clearance to wall or between boilers.
• Side clearance typical each side.
Top 356
Side 76
Rear 508
Front 914
