Cleco 5 Series - Parts Lists - Angle Heads; C and F Angle Head Components

8
PARTS LIST "F" RIGHT ANGLE HEAD
QTY.
1
1
1
1
1
1
1
1
1
*
*
1
1
24
1
1
1
1
1
847846
202983
612229
867921
867922
863035
202985
202982 1/4" SQ. DR.
202989 1/4"-28 Drill
202986
202988
847853
202987
202984
864964
ANGLE HEAD ADAPTER
STALL TOOLS ONLY
869679
.002" 614263
.005" 863216
.010" 614264
The complete right angle head can be purchased
using these part numbers. 1/4" sq. dr. - 201266
1/4" - 28 drill - 201267
* Number of shims required is variable.
**Parts included in 202982 1/4" sq. dr.
PART NO.
202000
202001
202002
202003
202004
614263
614264
812901
844111
845835
847597
847846
847852
847853
847854
863035
863216
864964
869434
869679
PARTS LIST "C" RIGHT ANGLE HEAD
NAME OF PART
Angle Head (incl. 864964)
Bearing Plug
Gear Bushing
Pinion
1/4" Sq. Dr. Spindle (incl. 202986,
202987, 844111, 847853)
Head Positioning Shim .002"
Head Positioning Shim .010"
Retainer Ring
Gear Pin
Pinion Needle Bearing
Driven Gear Needle Bearing
Pinion Ball Bearing
Lock Pin Retainer Plug
Lock Pin Spring
Socket Lock Pin
Steel Ball 1/16"
Head Positioning Shim .005"
Grease Fitting
Clutch Spacer (Clutch Models
Only)
Angle Head Adapter (Stall Models
Only)
QTY.
1
1
1
1
1
*
*
1
1
1
1
1
1
1
1
20
*
1
1
1
"C" RIGHT ANGLE HEAD
The complete right angle head can be purchased
using this number 861945.
* Number of shims required is variable.
"F" RIGHT ANGLE HEAD
202003
845835
847597
844111
863035
202002
202004 1/4" sq. dr.
202066 1/4-28 drill spindle
202068 9/32-40 drill spindle
847854
202001
847853
847852
202000
864964
812901
Clutch Model Only
869434
847846
ANGLE HEAD ADAPTER
STALL TOOLS ONLY
869679
.002" 614263
.005" 863216
.010" 614264
PART NO.
202982
202983
202984
202985
202986
202987
202988
202989
612229
614263
614264
847846
847853
863035
863216
864964
867921
867922
869679
NAME OF PART
1/4" Sq.Dr.(incl.202986, 202987,
867922, 847853)
Pinion
Angle Head
Gear Bushing
Plug**
Plunger**
Bearing Cap
1/4- 28 Drill Spindle
Needle Bearing
Angle Head Positioning Shim .002"
Angle Head Positioning Shim .010"
Bearing, Ball
Spring**
Ball
Angle Head Positioning Shim .005"
Oil Hole Cover
Needle Bearing
Gear Pin**
Angle Head Adapter
