1 - 14 System Map: Bottom View
Quick Start Guide
1
System Map: Bottom View
Figure 1 - 6
Bottom View
1. Battery
2. Hard Disk Bay
Cover
(3.5G Module
Location)
3. RAM & CPU Bay
Cover
2
3
1
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely
discharge and charge the battery at least once every 30 days or after about 20 partial dis-
charges. See “Battery Information” on page 3 - 10 for full instructions.
CPU
The CPU is not a user serviceable
part. Opening this compartment,
or accessing the CPU in any way,
may violate your warranty.
Overheating
To prevent your computer from
overheating make sure nothing
blocks the Vent/Fan Intake while
the computer is in use.
