6 - 6 Upgrading the Optical (CD/DVD) Device
6
Upgrading the Optical (CD/DVD) Device
1. Turn off the computer, and turn it over and remove the battery.
2. Locate the RAM & CPU bay cover and remove screws
- .
3. Remove the screw at point , and use a screwdriver to carefully push out the
optical device at point .
4. Reverse the process to install the new device.
Figure 6 - 4
Removing the CD/
DVD Device
1 4
5
5
5
5
1
3
4
2
