Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery.
1. Turn the computer off, remove the AC/DC adapter and turn it over.
2. Loosen screws - and carefully lift the battery up.
3. Lift the battery up (Figure b) and out of the battery bay.
Figure 1
Battery Removal
a. Loosen the screws.
b. Release the battery.
c. Lift the battery out of the
bay as indicated.
To Next Page
