Clevo P570WM Service Manual

Introduction
1 - 2 System Specifications
1.Introduction
System Specifications
Processor Options
Intel® Core™ i7-3960X (3.30GHz)
15MB L3 Cache, 32nm, DDR3-1600MHz, TDP
130W
Intel® Core™ i7-3930K (3.20GHz)
12MB L3 Cache, 32nm, DDR3-1600MHz, TDP
130W
Intel® Core™ i7-3820 (3.60GHz)
10MB L3 Cache, 32nm, DDR3-1600MHz, TDP
130W
LCD (P570WM)
17.3" (43.94cm) FHD LCD
LCD (P570WM3)
17.3" (43.94cm) FHD LCD
Supports 3D solution with NV 3D VISION Kit
(Shutter Glasses Only)
Core Logic
Intel® X79 Chipset
Memory
Four 204 Pin SO-DIMM Sockets Supporting
DDR3 1333/1600MHz Memory
Memory Expandable up to 32GB
(The real memory operating frequency depends
on the FSB of the processor.)
BIOS
AMI BIOS (64Mb SPI Flash-ROM)
Storage
Up to Three (Factory Option) Changeable 2.5"
(6cm) 9.5mm (h) SATA (Serial) Hard Disk Drives
supporting RAID level 0/1/5
One 12.7mm(h) Optical Device Type Drive
(Super Multi Drive/Blu-Ray Combo Drive/Blu-Ray
Writer Drive)
Video Adapter (P570WM)
nVIDIA® GeForce GTX 680M PCIe Video Card
4GB GDDR5 Video RAM on board
Microsoft DirectX® 11 Compatible
Supports nVIDIA® SLI Technology
nVIDIA® GeForce GTX 670MX PCIe Video
Card
3GB GDDR5 Video RAM on board
Microsoft DirectX® 11 Compatible
Supports nVIDIA® SLI Technology
Video Adapter (P570WM3)
nVIDIA® GeForce GTX 680M PCIe Video Card
4GB GDDR5 Video RAM on board
Microsoft DirectX® 11 Compatible
Supports nVIDIA® SLI Technology
Supports 3DTV Play
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Fingerprint Reader Module
TPM 1.2
Keyboard
Illuminated Full-size “WinKey” keyboard (with
numeric keypad)
Pointing Device
Built-in Touchpad (scrolling key functionality inte-
grated)
Card Reader
Embedded Multi-In-1 Push-Push Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
MS (Memory Stick) / MS Pro / MS Duo
Slots
One ExpressCard (54/34) Slot
One Mini Card Slot for WLAN Module or WLAN
and Bluetooth Combo Module
Communication
Built-In Gigabit Ethernet LAN
(Factory Option) 2.0M FHD/ 2.0M HD USB PC
Camera Module
(Factory Option) Bluetooth 2.1 + EDR
(Enhanced Data Rate) Module
WLAN/ Bluetooth Half Mini-Card Modules:
(Factory Option) Intel® Centrino® Ultimate-N
6300 Wireless LAN (802.11a/g/n)
(Factory Option) Intel® Centrino® Advanced-N
6235 Wireless LAN (802.11a/g/n) + Bluetooth
4.0
(Factory Option) Intel® Centrino® Wireless-N
2230 Wireless LAN (802.11b/g/n) + Bluetooth
4.0
(Factory Option) Wireless LAN (802.11b/g/n) +
Bluetooth 4.0
Audio
High Definition Audio Compliant Interface
S/PDIF Digital Output
Five Speakers
One Sub Woofer
Built-In Microphone
Sound Blaster® X-Fi™ MB2
