Introduction
Mainboard Overview - Bottom (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Connectors)
Figure 10
Mainboard Bottom
Connectors
1. HDMI-Out Port
2. USB 3.0/3.1 Port
3. DC-In Jack
4. 126 Pin Audio
Connector
5. 22 Pin Audio
Connector
6. Battery
Connector
1 2 3
4
6
5
