30
English
Interface
Three USB 3.0 (USB 3.1 Gen 1) Type-A
Ports (Including one AC/DC Powered USB
Port)
Two USB 3.1 Gen 2 Type-C Ports*
*The maximum amount of current supplied
by USB Type-C ports is 500mA (USB 2.0)/
900mA (USB 3.1).
Two Mini DisplayPorts (1.3)
One HDMI-Out Port
One 2-In-1 Audio Jack (Headphone & S/
PDIF-Out (Optical) Combo Jack)
One Microphone-In Jack
One RJ-45 LAN
Jack
One DC-In Jack
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth
Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Card Reader
Embedded Multi-In-1 Push-Push Card
Reader
MMC (MultiMedia Card)/RS MMC
SD (Secure Digital)/Mini SD/SDHC/
SDXC (up to UHS-II)
Communication
Built-In 10/100/1000Mb Base-TX Ethernet
LAN
2.0M FHD PC Camera Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wire-
less-AC 9260 Wireless LAN (802.11ac) +
Bluetooth
(Factory Option) Intel® Dual Band Wire-
less-AC 9560 Wireless LAN (802.11ac) +
Bluetooth
(Factory Option) Intel® Dual Band Wire-
less-AC 9462 Wireless LAN (802.11ac) +
Bluetooth
(Factory Option) Qualcomm® Atheros
Killer™ Wireless-AC 1550i Wireless LAN
(802.11ac) + Bluetooth
(Factory Option) Intel® Wi-Fi 6 AX-200
Wireless LAN (802.11ax) + Bluetooth
Features
Intel® Optane™ Technology (for Intel Core
processor family)
Virtual Reality Ready
Windows® Mixed Reality Compatible
(Factory Option) USB Drive
Environmental Spec
Temperature
Operating: 5
°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Embedded 4-Cell Polymer Battery Pack,
55WH
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 7.7A (150W)
Dimensions & Weight
380mm (w) * 255mm (d) * 18.6mm (h)
1.98kg (Barebone with 55WH Battery)
CPU Speed & Computer in DC
Mode
Note that when the computer is in
DC mode (powered by the battery
only) the CPU may not run at full
speed. This is a design feature im-
plemented in order to protect the bat-
tery.
P955RT.book Page 30 Friday, June 21, 2019 1:45 PM
