Clevo W251HPQ User Manual

Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow (Figure 1a
).
3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a
).
4. Slide the battery in the direction of the arrow (Figure 1b
).

3. Battery
1
2
6
3
4
Figure 1
Battery Removal
a. Slide the latch and hold it
in place.
b. Slide the battery in the di-
rection of the arrow.
1
a.
b.
3
2
4

Clevo W251HPQ Specifications

General

RAM	Up to 4GB
Memory Type	DDR3
Memory Slots	2
Optical Drive	DVD Super Multi
Display	15.6 inches
Resolution	1366x768 pixel
Operating System	Windows 7
Battery	6-cell Li-ion
