Clevo W650SB - Removing the Hard Disk Drive

Disassembly
Removing the Hard Disk Drive 2 - 7
2.Disassembly
Removing the Hard Disk Drive
The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm
or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as
outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
Hard Disk Upgrade Process
Figure 3
HDD Assembly
Removal
a. Remove the screws.
b. Remove the component
bay cover.

3. Component Bay
Cover
•2 Screws
1. Turn off the computer, and remove the battery (page 2 - 5).
2. Locate the component bay cover and remove screws - (Figure 3a
).
3. Slide the component bay cover until the cover and case indicators are aligned (Figure 3b).
1
2
3
4
1
b.
3
a.
2
4
4
