Clevo W670RCQ - Page 42

Disassembly
2 - 18 Removing the CCD
2.Disassembly
5. Disconnect the cable (Figure 13d).
6. Remove the CCD module (Figure 13e).
7. Reverse the process to install a new CCD module.
6
7
e.
d.
7
6

7. CCD Module
Figure 13
CCD Removal
(cont’d)
d. Disconnect the cable.
e. Remove the CCD mod-
ule.
