Clevo W670RCQ - Removing the Hard Disk Drive

Disassembly
Removing the Hard Disk Drive 2 - 7
2.Disassembly
Removing the Hard Disk Drive
The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm
or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as
outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
Hard Disk Upgrade Process
Figure 3
HDD Assembly
Removal
a. Remove the screws. Lift
the component bay cov-
er off the computer.

3. Component Bay
Cover
•2 Screws
1. Turn off the computer, and remove the battery (page 2 - 5).
2. Locate the component bay cover and remove screws - (Figure 3a
).
3. Lift the component bay cover off the computer case by applying pressure at points & ; if you have prob-
lems using a finger to do this, then use a non-abrasive, non-sharp object (e.g. a coin) to lift the cover up before
removal).
1
2
3
4
5
1
3
a.
2
4
5
