DMX protocol
CHANNEL FUNCTION VALUE SETTING REMARK
1 Cyan 0-255 Cyan from min. saturation --> full cyan
2 Magenta 0-255 Magenta from min. saturation --> full magenta
3 Yellow 0-255 Yellow from min. saturation --> full yellow
4 Color wheel
0-4 Open / White
5-8 White + Red
9-12 Red
13-17 Red + Orange
18-21 Orange
22-25 Orange + Aquamarine
26-29 Aquamarine
30-34 Aquamarine + Green
35-38 Green
39-42 Green + Light Green
43-46 Light Green
47-51 Light Green + Lavender
52-55 Lavender
56-59 Lavender + Pink
60-63 Pink
64-68 Pink + Yellow
69-72 Yellow
73-76 Yellow + Magenta
77-81 Magenta
82-85 Magenta + Cyan
86-89 Cyan
90-93 Cyan + CTO 260/ + CTO2
94-98 CTO 260/CTO2
99-102 CTO 260 + CTO 190/CTO2 + CTO1
103-106 CTO 190/CTO1
107-110 CTO 190 + CTB 8000/CTO1 + CTB
111-115 CTB 8000/CTB
116-119 CTB 8000 + Blue/CTB
120-123 Blue
124-127 Blue + White
128-191 Forwards rainbow e󰀨ect from fast to slow
192-255 Backwards rainbow e󰀨ect from slow to fast
