CHANNEL FUNCTION VALUE SETTING REMARK
7
Shaking gobos
from slow to
fast
190-199 Gobo14
200-225 Forwards gobo wheel rotation from Fast to Slow
226-229 Stop
230-255 Backwards gobo wheel rotation from slow to fast
8 Prism wheel
0-63 Unused range
64-127 Prism1
128-191 Prism2
192-255 Prism1+Prism2
9
Prism wheel
indexing/
rotation
0 Unused range
1-63 Angle linear adjustment
64-127 Forwards Prism rotation from fast to slow
128-191 Backwards Prism rotation from slow to fast
192-207 90° bounce forwards / backwards from slow to fast/0-90°
208-223 180° bounce forwards / backwards from slow to fast/0-180°
224-239 270° bounce forwards / backwards from slow to fast/0-270°
240-255 360° bounce forwards / backwards from slow to fast/0-360°
10 Prism Macro
0-15 Unused range
16-55 From fast to slow, 8 prism bump
56-95 From fast to slow, 16 prism bump
96-135 From fast to slow, 8 prism+16 prism at the same time bump
136-175 8 prism + 16 prism bump from fast to slow
176-215 16 prism + 8 prism bump from fast to slow
216-255 From fast to slow, 8 prism and 16 the prism bump
11 Frost 0-255 Frost from 0% to 100% (0=default)
12 Focus 0-255 Continuous adjustment from far to near(128=default)
13 Pan 0-255 Pan movement by 540°(128=default)
14 Pan Fine 0-255 Fine control of pan movement(0=default)
15 Tilt 0-255 Tilt movement by 265°(128=default)
16 Tilt Fine 0-255 Fine control of tilt movement(0=default)
17 Function
0-25 Unused range
26-30
Cyan/Magenta/Yellow/Shutter/Strobe/Colour/Gobo/Prism/
Frost/Focus reset (head motor reset)
31-35 Pan/Tilt reset
36-40 System reset
41-180 Unused range
181-200 Lamp O
201-220 Unused range
221-255 Lamp On
