Tranquility
®
30 Digital (TE) Series IOM - 60Hz HFC-410A
Rev.: 29 May, 2015J
Refer to the Tranquility
®
30 Digital Product Catalog for unit performance at Part Load operation and for performance data without vFlow
™
.
Table 17a: Performance Data — Tranquility
®
30 Digital - Model 026
Full Load - with vFlow
™
Performance capacities shown in thousands of Btuh Antifreeze use recommended in this range. Also Clip JW3 on DXM2 board.
EWT
°F
Cooling - EAT 80/67 °F Heating - EAT 70°F
GPM
WPD
CFM TC SC kW EER HR LWT HWC GPM
WPD
CFM HC kW COP HE LAT LWT HWC
PSI FT PSI FT
20
1.3 0.3 0.6 750 29.3 18.1 1.16 33.2 25.3 70.0 1.4 6.0 1.9 4.4 840 16.5 1.73 2.8 10.7 88.2 16.4 1.5
1.4 0.3 0.6 850 29.8 19.5 1.20 33.9 24.9 70.0 1.4 6.0 1.9 4.4 950 16.8 1.68 2.9 11.0 86.3 16.3 1.5
30
1.7 0.3 0.7 750 29.3 18.1 1.16 33.2 25.3 70.0 1.4 3.0 0.7 1.6 840 18.2 1.69 3.2 12.6 90.1 21.6 1.7
1.7 0.3 0.7 850 29.8 19.5 1.20 33.9 24.9 70.0 1.4 3.0 0.7 1.6 950 18.5 1.64 3.3 12.9 88.0 21.4 1.8
1.7 0.3 0.7 750 29.3 18.1 1.16 33.2 25.3 70.0 1.4 4.5 1.1 2.6 840 19.1 1.68 3.3 13.4 91.0 24.0 1.8
1.7 0.3 0.7 850 29.8 19.5 1.20 33.9 24.9 70.0 1.4 4.5 1.1 2.6 950 19.4 1.63 3.5 13.8 88.9 23.9 1.9
1.7 0.3 0.7 750 29.3 18.1 1.16 33.2 25.3 70.0 1.4 6.0 1.8 4.0 840 19.5 1.67 3.4 13.9 91.5 25.4 1.9
1.7 0.3 0.7 850 29.8 19.5 1.20 33.9 24.9 70.0 1.4 6.0 1.8 4.0 950 19.8 1.62 3.6 14.3 89.3 25.2 1.9
40
2.2 0.4 1.0 750 29.3 18.1 1.16 33.2 25.3 70.0 1.4 3.0 0.6 1.5 840 21.0 1.66 3.7 15.4 93.1 29.7 2.1
2.3 0.4 1.0 850 29.8 19.5 1.20 33.9 24.9 70.0 1.4 3.0 0.6 1.5 950 21.3 1.61 3.9 15.8 90.8 29.5 2.1
2.2 0.4 1.0 750 29.3 18.1 1.16 33.2 25.3 70.0 1.4 4.5 1.1 2.5 840 22.0 1.65 3.9 16.5 94.3 32.7 2.2
2.3 0.4 1.0 850 29.8 19.5 1.20 33.9 24.9 70.0 1.4 4.5 1.1 2.5 950 22.4 1.60 4.1 16.9 91.8 32.5 2.3
2.2 0.4 1.0 750 29.3 18.1 1.16 33.2 25.3 70.0 1.4 6.0 1.6 3.8 840 22.6 1.64 4.0 17.1 94.9 34.3 2.3
2.3 0.4 1.0 850 29.8 19.5 1.20 33.9 24.9 70.0 1.4 6.0 1.6 3.8 950 23.0 1.59 4.2 17.5 92.4 34.2 2.3
50
3.0 0.6 1.4 750 29.1 18.0 1.19 33.1 24.5 72.0 1.4 3.0 0.6 1.4 840 23.8 1.64 4.2 18.2 96.2 37.8 2.4
3.0 0.6 1.4 850 29.6 19.4 1.23 33.8 24.0 72.5 1.5 3.0 0.6 1.4 950 24.1 1.59 4.5 18.7 93.5 37.5 2.5
3.3 0.7 1.6 750 29.3 18.1 1.16 33.2 25.3 70.0 1.4 4.5 1.0 2.3 840 25.1 1.64 4.5 19.5 97.6 41.3 2.6
3.4 0.7 1.6 850 29.8 19.5 1.20 33.9 24.9 70.0 1.4 4.5 1.0 2.3 950 25.4 1.59 4.7 20.0 94.8 41.1 2.6
3.3 0.7 1.6 750 29.3 18.1 1.16 33.2 25.3 70.0 1.4 6.0 1.6 3.6 840 25.8 1.64 4.6 20.2 98.4 43.3 2.7
3.4 0.7 1.6 850 29.8 19.5 1.20 33.9 24.9 70.0 1.4 6.0 1.6 3.6 950 26.2 1.59 4.8 20.7 95.5 43.1 2.7
60
3.0 0.6 1.3 750 27.9 17.6 1.30 32.3 21.4 81.5 1.9 3.0 0.6 1.3 840 26.7 1.64 4.8 21.1 99.4 45.9 2.8
3.0 0.6 1.3 850 28.4 18.9 1.35 33.0 21.0 82.0 1.9 3.0 0.6 1.3 950 27.1 1.59 5.0 21.6 96.4 45.6 2.8
4.5 1.0 2.3 750 28.8 17.9 1.22 32.9 23.7 74.6 1.5 4.5 1.0 2.3 840 28.2 1.65 5.0 22.5 101.0 50.0 2.9
4.5 1.0 2.3 850 29.3 19.3 1.26 33.6 23.3 74.9 1.6 4.5 1.0 2.3 950 28.6 1.60 5.2 23.1 97.9 49.7 3.0
6.0 1.5 3.5 750 29.2 18.1 1.18 33.1 24.8 71.0 1.4 6.0 1.5 3.5 840 29.0 1.66 5.1 23.3 102.0 52.2 3.0
6.0 1.5 3.5 850 29.7 19.4 1.22 33.8 24.3 71.3 1.4 6.0 1.5 3.5 950 29.4 1.61 5.4 24.0 98.7 52.0 3.1
70
3.0 0.6 1.3 750 26.4 17.0 1.43 31.3 18.5 90.9 2.4 3.0 0.6 1.3 840 29.6 1.66 5.2 23.9 102.6 54.1 3.1
3.0 0.6 1.3 850 26.9 18.3 1.48 32.0 18.2 91.3 2.4 3.0 0.6 1.3 950 30.1 1.61 5.5 24.6 99.3 53.6 3.2
4.5 1.0 2.2 750 27.5 17.5 1.33 32.0 20.7 84.2 2.0 4.5 1.0 2.2 840 31.4 1.69 5.4 25.6 104.6 58.6 3.3
4.5 1.0 2.2 850 28.0 18.8 1.38 32.7 20.3 84.5 2.1 4.5 1.0 2.2 950 31.8 1.64 5.7 26.2 101.0 58.3 3.3
6.0 1.5 3.4 750 28.0 17.7 1.28 32.4 21.8 80.8 1.8 6.0 1.5 3.4 840 32.3 1.71 5.5 26.5 105.7 61.2 3.4
6.0 1.5 3.4 850 28.5 19.0 1.33 33.1 21.4 81.0 1.9 6.0 1.5 3.4 950 32.8 1.66 5.8 27.2 102.0 60.9 3.4
80
3.0 0.6 1.3 750 24.8 16.3 1.58 30.2 15.7 100.1 3.0 3.0 0.6 1.3 840 32.6 1.71 5.6 26.7 106.0 62.2 3.4
3.0 0.6 1.3 850 25.2 17.5 1.64 30.8 15.4 100.5 3.0 3.0 0.6 1.3 950 33.1 1.66 5.8 27.5 102.3 61.7 3.5
4.5 0.9 2.2 750 26.0 16.8 1.48 31.0 17.6 93.8 2.6 3.7 0.7 1.7 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
4.5 0.9 2.2 850 26.4 18.1 1.53 31.6 17.3 94.1 2.6 3.8 0.8 1.8 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
6.0 1.4 3.3 750 26.2 16.9 1.45 31.1 18.1 90.4 2.4 3.7 0.7 1.7 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
6.0 1.4 3.3 850 26.7 18.2 1.50 31.8 17.8 92.7 2.4 3.8 0.8 1.8 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
90
3.0 0.6 1.3 750 23.1 15.5 1.75 29.0 13.2 109.4 3.7 2.2 0.4 0.9 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
3.0 0.6 1.3 850 23.5 16.7 1.81 29.7 13.0 109.8 3.7 2.3 0.4 1.0 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
4.5 0.9 2.2 750 24.3 16.1 1.63 29.8 14.9 103.2 3.2 2.2 0.4 0.9 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
4.5 0.9 2.2 850 24.7 17.3 1.69 30.4 14.6 103.5 3.3 2.3 0.4 1.0 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
6.0 1.4 3.2 750 24.9 16.3 1.57 30.2 15.8 100.1 3.0 2.2 0.4 0.9 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
6.0 1.4 3.2 850 25.3 17.5 1.63 30.9 15.5 100.3 3.0 2.3 0.4 1.0 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
100
3.0 0.6 1.3 750 21.3 14.8 1.95 28.0 10.9 118.7 4.4 1.6 0.2 0.6 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
3.0 0.6 1.3 850 21.7 15.9 2.02 28.6 10.7 119.1 4.5 1.6 0.3 0.6 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
4.5 0.9 2.1 750 22.5 15.3 1.81 28.7 12.4 112.7 3.9 1.6 0.2 0.6 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
4.5 0.9 2.1 850 22.9 16.4 1.88 29.3 12.2 113.0 4.0 1.6 0.3 0.6 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
6.0 1.4 3.2 750 23.1 15.5 1.76 29.0 13.1 109.7 3.7 1.6 0.2 0.6 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
6.0 1.4 3.2 850 23.5 16.7 1.82 29.7 12.9 109.9 3.7 1.6 0.3 0.6 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
110
3.0 0.6 1.3 750 19.7 14.2 2.18 27.1 9.0 128.1 5.3 1.2 0.1 0.3 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
3.0 0.6 1.3 850 20.0 15.2 2.26 27.7 8.9 128.5 5.4 1.3 0.1 0.3 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
4.5 0.9 2.1 750 20.7 14.6 2.04 27.7 10.2 122.3 4.7 1.2 0.1 0.3 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
4.5 0.9 2.1 850 21.1 15.7 2.11 28.2 10.0 122.6 4.8 1.3 0.1 0.3 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
6.0 1.4 3.1 750 21.3 14.8 1.96 28.0 10.8 119.3 4.4 1.2 0.1 0.3 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
6.0 1.4 3.1 850 21.6 15.9 2.03 28.6 10.6 119.5 4.5 1.3 0.1 0.3 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
120
3.0 0.5 1.2 750 18.2 13.7 2.46 26.6 7.4 137.7 6.2 1.0 0.1 0.2 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
3.0 0.5 1.2 850 18.5 14.7 2.55 27.2 7.3 138.1 6.4 1.0 0.1 0.2 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
4.5 0.9 2.0 750 19.1 14.0 2.29 26.9 8.3 132.0 5.6 1.0 0.1 0.2 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
4.5 0.9 2.0 850 19.4 15.0 2.37 27.5 8.2 132.2 5.8 1.0 0.1 0.2 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
6.0 1.3 3.1 750 19.5 14.1 2.20 27.1 8.9 129.0 5.3 1.0 0.1 0.2 840 33.9 1.74 5.7 27.9 107.4 65.0 3.5
6.0 1.3 3.1 850 19.9 15.2 2.28 27.7 8.7 129.2 5.5 1.0 0.1 0.2 950 34.4 1.69 6.0 28.7 103.6 65.0 3.6
Interpolation is permissible; extrapolation is not. All performance is based upon the lower voltage of dual voltage rated units.
Flow is controlled to maintain minimum LWT 70° F in cooling and maximum LWT 65° F in heating. Operation at or below 40° F EWT is based on 15% methanol antifreeze solution.
Table does not refl ect fan or pump power corrections for AHRI/ISO conditions. See Performance correction tables for operating conditions other than those listed above.
For operation in the shaded areas, please see the Performance Data Selection Notes.
