ClimateMaster Tranquility TSV 070 - TS Blower Performance Data (PSC Motor) - Units with ClimaDry

CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
20 (TS) Series
Rev.: June 5, 2020
ClimateMaster Water-Source Heat Pumps
32
TS Blower Performance Data (PSC Motor) – Units with ClimaDry
®
Coil Face
Velocity
FPM
TSH/V/D with Reheat ESP Loss
TSH/V/D
018
In. of Water
TSH/V/D
024, 030
In. of Water
TSH/V/D
036
In. of Water
TSH/V/D
042, 048
In. of Water
TSH/V/D
060, 070
In. of Water
200 0.037 0.033 0.031 0.028 0.026
250 0.052 0.046 0.042 0.038 0.034
300 0.077 0.066 0.059 0.051 0.044
350 0.113 0.096 0.085 0.073 0.061
400 0.181 0.160 0.145 0.131 0.117
450 0.242 0.226 0.215 0.205 0.194
500 0.360 0.345 0.335 0.326 0.316
For TS units with ClimaDry Reheat coil applications,
calculate face velocity of the entering air. From the table
above, nd ESP for Reheat application. The loss includes
wet coil loss.
Example:
Reheat coil loss can be determined from the above table.
Coil velocity (FPM) = Airow (CFM) / Face Area (sq. ft.)
1. TSH036 has a face area of 4.86 sq. ft. (see physical
data table).
2. At 1,100 cfm, coil velocity (FPM) = 1,100 / 4.86 = 226
FPM
3. From above table, it will be necessary to subtract
0.037 from the blower performance ESP.
4. On medium speed, the TSH036 (without reheat - see
blower table) can deliver 1,100 CFM at 0.28 in. wg.
with the standard PSC motor; with the reheat coil, it
now delivers 1,085 CFM at 0.28 in. wg. or 1,100 CFM
at 0.24 in. wg.
5. If the decrease in airow is acceptable, no changes are
necessary. Otherwise, high speed fan should be used
to overcome the pressure drop of the reheat coil.
Unit minimum entering air temperature while in the
dehumidication, cooling, or continuous fan modes is
65ºF DB/55ºF WB. Operation below this minimum may
result in nuisance faults.
