24
- Verify, during the operation, the electrical absorption
of the water pump (if installed): it must correspond to
the data indicated on the wiring diagram. In contrary
case it means that the pump is not working in curve.
Act on the shut off valve placed after the pump in order
to go back to acceptable values.
6.3.2 Defrosting
(Only heat pump units)
During operation in the winter cycle (heat pump), the coil
works as an evaporator, cooling and dehumidifying the
external air. Depending on the temperature and moisture
of the external air, condensation or frost will form.
The frost accumulated on the coil obstructs the air inlet
thereby reducing air flow and the heat transfer rate.
The heat pump units are fitted with control devices that
automatically defrost the coil whenever necessary. This
control device features a temperature probe placed on
the coil which, when the temperature is equal to or lower
than the set-point, activates the defrost cycle function
which will take place only if a certain time (default set-
ting: 30 minutes) has elapsed since the last defrosting
process.
Defrosting takes place as follows:
- the fans stop;
- the operating cycle is inverted with the 4-way valve,
thereby making the finned coil work like a condenser.
The condensation heat causes the frost to melt and
drain to the ground.
When the end-of-cycle pressure is reached, the 4-way
valve is inverted once more and the winter operating
cycle continues.
Defrosting lasts from about 1 to a maximum of 5 minutes
when it is interrupted even if the end-of-cycle pressure
set-point has not been reached.
6.4 STOPPING THE UNIT
Stop the unit by pressing the “OFF” key on the front
panel.
Attention!
Do not stop the unit by turning off the main
power switch as this would also disconnect
both the heating elements of the sump and
the possible autifreeze kits which would
affect compressor operation after start
up.
- W trakcie pracy sprawdź pobór mocy pompy wodnej (je-
żeli zosta zainstalowana): musi być zgodny z danymi
wskazanymi na schemacie pączeń. Niezgodnć tych
danych oznacza, że pompa nie pracuje zgodnie z krzywą
charakterystyki. Dokonaj regulacji zaworu odcinającego,
znajducego się za pompą, w celu ustawienia dopusz-
czalnych wartości.
6.3.2 Odszranianie
(tylko dla wersji pompa ciepła)
W czasie pracy w sezonie zimowym (pompa ciepła),
skraplacz działa jako parownik, chłodząc lub osuszając
zewnętrzne powietrze. W zależności od temperatury i
wilgotności zewnętrznego powietrza, będzie tworzsię
kondensacja lub szron.
Szron gromadzący się na skraplaczu blokuje wylot po-
wietrza, redukując tym samym przepływ powietrza i po-
ziom wymiany ciepła.
Urządzenia typu pompa ciepła wyposażone są w urzą-
dzenia sterujące, które automatycznie uruchamiają od-
szranianie skraplacza w razie konieczności. Urządzenie
sterujące wyposone jest w czujnik temperatury umiesz-
czony na skraplaczu, który po osiągnięciu temperatury
równej lub niższej od punktu nastawy, aktywuje cykl od-
szraniania, kry zadzia tylko jeli mił określony czas
(ustawienie domyślne: 30 minut) od ostatniego cyklu
odszraniania.
Przebieg cyklu odszraniania
:
- zatrzymanie wentylatorów;
- cykl pracy jest przestawiany przez zawór 4-drogowy
powoduc, że ebrowana wężownica pracuje jak
skraplacz. Skupione ciepło powoduje topnienie szronu
i odprowadzenie powstałych skroplin do tacy skroplin.
Kiedy ciśnienie końca cyklu odszraniania zostanie osiąg-
nięte, zawór 4-drogowy ponownie przełączy tryb pracy
i cykl pracy zimowej będzie kontynuowany.
Cykl odszraniania trwa od około 1 do maksymalnie 5
minut, kiedy zostanie przerwany nawet jeżeli ciśnienie
końca cyklu nie zostanie osiągnięte.
6.4 ZATRZYMANIE PRACY JEDNOSTKI
Uwaga!
Nie zatrzymuj urządzenia przełączając głów-
ny wyłącznik zasilania, poniew spowoduje
to również wyłączenie elementów grzewczych
karteru i ewentualnych zabezpieczeń antyszro-
nieniowych, co może wpłynąć negatywnie na
pra
cę spżarki po ponownym uruchomieniu.
Zatrzymaj urządzenie, wciskając przycisk OFF na
przednim panelu.
