Page 56
Model
IF2-XY 140M
Pipe Length (m)
MC2-Y 140T
Cooling 5 15 25 35 50 65
Height
difference
H (m)
Indoor Upper
than Outdoor
30 0.880 0.838 0.796
20 0.918 0.889 0.846 0.804
10 0.956 0.927 0.898 0.855 0.812
5 0.995 0.966 0.937 0.907 0.864 0.820
0 1.000 0.971 0.941 0.912 0.868 0.824
Outdoor Upper
than Indoor
-5 1.000 0.971 0.941 0.912 0.868 0.824
-10 0.971 0.941 0.912 0.868 0.824
-20 0.941 0.912 0.868 0.824
-30 0.912 0.868 0.824
Heating 5 15 25 35 50 65
Height
difference
H (m)
Indoor Upper
than Outdoor
30 0.956 0.933 0.911
20 0.970 0.956 0.933 0.911
10 0.985 0.970 0.956 0.933 0.911
5 1.000 0.985 0.970 0.956 0.933 0.911
0 1.000 0.985 0.970 0.956 0.933 0.911
Outdoor Upper
than Indoor
-5 0.992 0.977 0.963 0.948 0.926 0.904
-10 0.969 0.955 0.940 0.918 0.896
-20 0.947 0.933 0.911 0.889
-30 0.925 0.904 0.882
