Note: DO NOT allow water to enter the remote control. Use the trap and putty to seal the wires.
• For exposed mounting, four outletting positions. There are three need cutting.
Cutting place of top
side wire outlet
Cutting place of left
side wire outlet
Cutting place of right
side wire outlet
• For shielded wiring, please refer to the picture below.
Embedded switch
box wiring
Wiring
hole
Wiring through the wall
Wall hole and wiring hole
