CLIVET MSAN-XMI 200T User Manual

44
Starting up the system
1
32
2
5
4(*)
Fig. 67
1 Outdoor unit
2 Indoor unit
3 Room with a refrigerant leak (maximum build-up of
refrigerant)
4 Ventilation opening
5 Leak detection alarm connected to the mechanical fan
(*) The leak signalling siren should be installed in a place that
is easy to reach from the refrigerant
l
WARNING
Press the “forced cooling” button to carry out
the refrigerant recirculation procedure. Keep
the minimum pressure above 0.2 MPa to avoid
possible damage to the compressor.
IMPORTANT INFORMATION ON THE REFRIGERANT
USED
This product contains fluorinated greenhouse gases
regulated by the Kyoto protocol. Do not release gases
into the atmosphere.
Type of refrigerant: R410A; GWP value: 2088;
GWP = global warming potential
Outdoor
unit cooling
capacity kW
Factory charge
Refrigerant/kg
Tons of
equivalent CO2
20-28 6.5 13.57
33.5 8 16.71
Frequency of refrigerant leakage checks:
– For appliances containing fluorinated greenhouse
gases of 5 tons or more of equivalent CO2 but
less than 50 tons of equivalent CO2, at least every
12 months or, where a leak detection system is
installed, at least every 24 months.
– For appliances containing fluorinated greenhouse
gases of 50 tons or more of equivalent CO2 but
less than 500 tons of equivalent CO2, at least
every six months or, where a leak detection system
is installed, at least every 12 months.
– For appliances containing fluorinated greenhouse
gases of 500 tons or more of equivalent CO2, at
least every three months or, where a leak detection
system is installed, at least every six months.
– Appliances containing fluorinated greenhouse
gases that are not hermetically sealed may
only be sold to end users when it is proven that
the installation will be carried out by a certified
professional.
– Installation, operation and maintenance should
only be carried out by certified professionals.
