46
Special functions
7.1.1 System control mode
80M-105M
Num
Description Notes
1
Normal view
The frequency will be displayed during operation and the number
of indoor units will be displayed in standby mode.
2
Operating mode
0 - Standby; 2 - Cooling; 3 - Heating;
4 - Forced cooling
3
Fan speed 0: Shutdown - 1
to 7: Increase the speed
4
Total capacity required of the indoor unit --
5
Capacity required of the outdoor unit --
6
Temperature of the pipes T3 Actual value
7
Room temperature T4 Actual value
8
Supply temperature T5
Actual value (if it is greater than one hundred, only the hundreds
and tens digits will be displayed)
9
Reserved --
10
EXV opening degree Actual value = value displayed x 8
11
Current value Actual value
12
AD voltage value Actual value
13
Average temperature T2 Actual value
14
Number of indoor units Actual value
15
Number of indoor units in operation Actual value
16
Model type 8KW: 8; 10KW: 10
17
Priority mode Reserved
18
Program version --
19
The latest malfunction or protection code
If there are no malfunctions or protection codes, “nn” will be displa-
yed.
20
Display “--” --
120M-160M
Num
Description Notes
1
Normal view
The frequency will be displayed during operation and the number
of indoor units will be displayed in standby mode.
2
Operating mode
0 - Standby; 2 - Cooling; 3 - Heating;
4 - Forced cooling
3
Fan speed 0: Shutdown - 1
to 7: Increase the speed
4
Total capacity required of the indoor unit --
5
Capacity required of the outdoor unit --
6
Temperature of the pipes T3 Actual value
7
Room temperature T4 Actual value
8
Supply temperature T5
Actual value (if it is greater than one hundred, only the hundreds
and tens digits will be displayed)
9
Reserved --
10
EXV opening degree Actual value = value displayed x 8
11
Current value Actual value
12
AD voltage value Actual value
13
Average temperature T2 Actual value
14
Number of indoor units Actual value
15
Number of indoor units in operation Actual value
16
The latest malfunction or protection code
If there are no malfunctions or protection codes, “nn” will be displa-
yed.
17
Display “--” --
