58
Electrical connections
7.5.3 Connection terminal block
Fig. 51
Ref. Terminal block CN11
1
1 SL1
Solar input
2 SL2
2
3 H
Room thermostat
(220V)
4 C
15 L1
3
5 1ON
SV1
DHW 3-way valve
6 1OFF
16 N
4
7 2ON
SV2
3-way zone
valve
8 2OFF
17 N
5
9 P_c
pump P_c (zone2)
21 N
6
10 P_o
pump P-o (zone1)
22 N
7
11 P_s
solar pump
23 N
8
12 P_d
DHW recirculation
pump
24 N
9
13 TBH
TBH heater
16 N
10
14 IBH1
External backup
heater
17 N
11
17 N
SV3
zone 2 3-way
mixing valve
7 ON
19 OFF
Ref. Terminal block CN7
1
26 R2
Unit in operation
signal
30 R1
21 DFT2
Defrosting state or
alarm state
32 DFT1
2
25 HT
Antifreeze heater
for pipes
29 N
3
27 AHS1
Additional boiler
28 AHS2
Ref. Terminal block CN30
1
1 A
Wired controller
2 B
3 X
4 Y
5 E
2
6 P
Reserved
7 Q
3
9 H1
M/S connection for
units in cascade
10 H2
