M01W45H6-06
WSAT-SC
75C-180F
- ELECTRICAL DATA -
14
SOUND LEVELS
SC (STANDARD) EN
Power supplied 33% - Ambient temperature 28°C
Sound Power Level (dB)
Sound
pressure
Sound
power
Sound Power Level (dB)
Sound
pressure
Sound
power
Octave band (Hz) level level Octave band (Hz) level level
Size
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
Size
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
75C
85 84 80 78 72 66 63 55 60 78
75C
82 83 79 76 71 67 62 56 59 78
90C
78 83 79 77 71 66 62 55 60 78
90C
82 82 78 76 71 67 63 56 59 77
135F
85 87 83 81 75 69 66 59 62 82
135F
86 87 82 77 75 70 64 60 61 80
150F
85 88 84 81 76 70 66 59 63 82
150F
87 87 83 79 75 70 65 61 61 81
165F
85 88 84 82 76 70 67 60 63 83
165F
86 87 83 80 75 71 66 60 62 82
180F
85 88 84 82 76 70 67 60 63 83
180F
86 87 83 80 75 71 66 60 62 81
Power supplied 50% - Ambient temperature 30°C
Sound Power Level (dB)
Sound
pressure
Sound
power
Sound Power Level (dB)
Sound
pressure
Sound
power
Octave band (Hz) level level Octave band (Hz) level level
Size.
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
Size
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
65D
96 92 93 89 85 81 74 68 72 91
65D
85 88 84 80 77 72 66 59 63 82
70D
96 92 92 89 85 81 74 67 72 91
70D
85 88 84 80 77 72 66 59 64 83
75D
96 92 92 89 85 81 74 67 72 91
75D
85 88 84 81 77 72 66 59 64 83
80D
96 92 92 89 85 81 74 67 72 91
80D
85 88 84 82 77 72 66 59 64 83
90D
96 92 92 89 85 81 74 67 72 91
90D
85 88 84 81 77 72 67 59 64 83
100D
96 92 93 89 85 81 74 67 72 91
100D
84 87 84 82 77 72 67 58 64 83
110D
98 94 95 91 87 83 76 70 74 93
110D
87 90 86 83 79 74 68 61 66 85
120D
97 95 95 92 88 83 77 70 74 94
120D
87 90 86 84 79 74 68 61 66 85
Power supplied 66% - Ambient temperature 30°C
Sound Power Level (dB)
Sound
pressure
Sound
power
Sound Power Level (dB)
Sound
pressure
Sound
power
Octave band (Hz) level level Octave band (Hz) level level
Size
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
Size
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
75C
89 91 91 88 84 80 73 66 71 90
75C
83 86 82 79 75 70 64 56 62 81
90C
92 91 92 89 84 80 74 66 72 90
90C
83 86 82 80 75 70 65 57 63 81
135F
99 96 97 93 89 85 78 72 75 95
135F
90 93 89 85 82 76 70 64 68 87
150F
100
96 97 94 90 85 79 72 75 95
150F
91 94 90 86 82 77 70 65 68 88
165F
100
97 98 94 90 86 79 73 76 96
165F
90 93 90 87 83 78 72 64 69 89
180F
100
97 97 94 90 86 79 72 76 96
180F
90 93 90 88 82 78 72 64 69 89
Power supplied 100% - Ambient temperature 35°C
Sound Power Level (dB)
Sound
pressure
Sound
power
Sound Power Level (dB)
Sound
pressure
Sound
power
Octave band (Hz) level level Octave band (Hz) level level
Size
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
Size
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
65D
99 95 96 92 88 84 77 71 75 94
65D
88 91 87 83 80 75 69 62 66 85
70D
99 95 95 92 88 84 77 70 75 94
70D
88 91 87 83 80 75 69 62 67 86
75C
92 94 94 91 87 83 76 69 74 93
75C
86 89 85 82 78 73 67 59 65 84
75D
99 95 95 92 88 84 77 70 75 94
75D
88 91 87 84 80 75 69 62 67 86
80D
99 95 95 92 88 84 77 70 75 94
80D
88 91 87 85 80 75 69 62 67 86
90C
95 94 95 92 87 83 77 69 75 93
90C
86 89 85 83 78 73 68 60 66 84
90D
99 95 95 92 88 84 77 70 75 94
90D
88 91 87 84 80 75 70 62 67 86
100D
99 95 96 92 88 84 77 70 75 94
100D
87 90 87 85 80 75 70 61 67 86
110D
101
97 98 94 90 86 79 73 77 96
110D
90 93 89 86 82 77 71 64 69 88
120D
100
98 98 95 91 86 80 73 77 97
120D
90 93 89 87 82 77 71 64 69 88
135F
101
98 99 95 91 87 80 74 77 97
135F
92 95 91 87 84 78 72 66 70 89
150F
102
98 99 96 92 87 81 74 77 97
150F
93 96 92 88 84 79 72 67 70 90
165F
102
99 100 96 92 88 81 75 78 98
165F
92 95 92 89 85 80 74 66 71 91
180F
102
99 99 96 92 88 81 74 78 98
180F
92 95 92 90 84 80 74 66 71 91
Measures according to ISO 3744 regulations, with respect to the EUROVENT 8/1 certification.
The sound pressure level is measured 1 metre the external surface of the unit operating in an open field. Data refer to the following
conditions: internal exchanger water = 12/7°C.
