M01W45H6-06
WSAT-SC
75C-180F
- ELECTRICAL CONNECTIONS -
27
EXTERNAL AIR TEMPERATURE PROBE - Optional
It allows the automatic correction of the set-point according to the external air temperature.
For example, in summer operating with low external temperatures, is possible to obtain the internal comfort also with set-
point values higher than the standard value.
It is necessary the parameter configuration.
MENU NUM Parameter name meaning
1 EnCompExt
External compensation enabling
0 = no; 1 = COOL only; 2 = HEAT only; 3 = always
4 MaxCExtC Max. ext. compensation value of the cooling
106 CextMaxC Max. ext. temp. of cooling compensation
parameter
control
compext
107 CextMinC Min. ext. temp. of cooling compensation
parameter-set-sensors 9 ProbeText It enables ext. temp. probe: 0=yes ; 1=non
SUMMER
p4
p106 p107 Text °C
set COMPENSATO
EXTERNAL AIR HUMIDITY PROBE - Optional
It allows the automatic correction of the set-point, according to external air enthalpy. The working process is similar to the
above mentioned process.
In winter operating, the correction is only on the temperature.
The operating is analogous to the above described.
It is necessary the parameter configuration.
MENU NUM Parameter name meaning
4 MaxCExtC Max. summer correction value
110 HexMinC Ext. enthalpy min. correction
parameter
control
compext
111 HexMaxC Ext. enthalpy max. correction
parameter-set-sensors 23 ProbeURExt It enables ext. humidity probe: 1=YES / 0=NO
