CLIVET WSAT-SC 135F Series User Manual

M01W45H6-06
WSAT-SC
75C-180F
- POSITIONING -
21
Sizes 110D-120D-135F-150F
W1 W2
W4W3
4
2125
O
P
4250
2280
N
7
0
0
(
1
1
)
2
1
2
5
3
5
985
6
3
0
2
0
0
2125
M
3
5
700
(10)
1
5
0
0
(
1
3
)
6
"G"
9
OD
3
4
7
8
6
5
1
2
4
1
0
2195
1
3
0
0
(
1
2
)
700
(10)
14
985
3
7
3
53
4
7
53
1
3
4
2
(1) INTERNAL EXCHANGER
(2) EXTERNAL EXCHANGER
(3) HOLE TO HANG UNIT
(4) LIFTING HOLES
(5) ELECTRICAL PANEL
(6) POWER INPUT
(7) SOUNDPROOFED CABIN
(8) INTERNAL EXCHANGER WATER INLET
(9) INTERNAL EXCHANGER WATER OUTLET
(10) MINIMUM DIMENSION FOR A SAFE PASSAGE.
(11) MINIMUM DIMENSION FOR A SAFE PASSAGE WHEN THE DOOR OF THE
ELECTRICAL SWITCHBOARD IS OPEN.
(12) MINIMUM DIMENSION FOR A PROPER AIR FLOW TO THE CONDENSER
COIL.
(13) MINIMUM DIMENSION ON THE ELECTRICAL SWITCHBOARD SIDE.
(14) CLEARANCE ACCESS RECOMMENDED
(G) BARYCENTRE
SC EN
SIZES 110D 120D 135F 150F 110D 120D 135F 150F
M
mm 2117 2117 2112 2112 2092 2117 2112 2112
N mm 2138 2139 2138 2138 2164 2139 2138 2138
O mm 1382 1392 1405 1403 1379 1391 1376 1388
P mm 815 805 789 791 818 806 818 806
OD mm 89 89 89 89 89 89 89 89
W1 kg 976 1009 1071 1079 979 1016 1077 1124
W2 kg 958 990 1046 1054 919 997 1052 1099
W3 kg 565 572 589 596 571 578 629 641
W4 kg 555 561 576 582 536 567 615 627
Weight referred to standard unit; according to the considered accessories unit weight can noticeably change.
