Unit in modular configuration
 Maximum 16 total units.
 Maximum 4 units in the same water branch.
 The modular system is controlled by the MASTER unit
(address=0), → Electrical connections
 All units must be electrically connected to each other con
cavo schermato a 3 conduttori → Electrical connections Each
module must be configured with the water fittings for modular
unit (AMOD).
 Each module can be equipped with inertial system storage
tank (ACIMP).
 It is necessary to provide an external pumping unit, sized for
the entire capacity of the modular system (responsibility of
the Customer). The pumping unit will be managed by the
Master unit through a potential-free contact and 0-10V signal
→ electrical connections
Opon
Code
Kit containing pipe closing caps for modular units
PESM00001
CCKMUX
Water fittings for modular unit
PEST00001
AMODX
1
2
3
4
