66
Size 18.2 - 20.2
Dimensional drawings
1. Compressor compartment
2. Electrical panel
3. Control keypad
4. Power input
5. Water inlet 2” Victaulic
6. Water outlet 2” Victaulic
7. Water tank**
8. Pump**
9. Isolating switch**
10. Functional spaces
DAASF0001_REV00
Data/Date 01/04/2021
SIZE 18.2 20.2
Lenght mm 2364 2364
Depth mm 1130 1130
Height mm 2152 2152
Operating weight kg 575 575
Shipping weight kg 560 560
Weight with water tank kg 615 615
Shipping weight with water tank kg 800 800
The presence of optional accessories may result in a substantial variation of the weights shown in the table.
**Optional
