62
General technical data
Performance
SIZE 18.2 20.2 25.2 30.2 35.2
Radiant panels
Cooling
Cooling capacity (EN 14511:2018) kW 1/4 61,7 72,1 88,1 94,5 108
EER (EN 14511:2018) 2 4,30 3,96 4,44 4,28 4,02
Water flow-rate l/s 1 2,95 3,44 4,21 4,51 5,14
User side exchanger pressure drops kPa 1 33,4 44,7 65,2 74,4 95,1
Terminal unit
Cooling
Cooling capacity (EN 14511:2018) kW 3 53,1 59,2 72,2 77,5 85,1
EER (EN 14511:2018) 2 3,10 3,00 3,21 3,20 3,10
SEER (EN 14511:2018) 5 4,85 4,84 4,89 4,81 4,74
Water flow-rate l/s 5 2,54 2,83 3,45 3,70 4,07
User side exchanger pressure drops kPa 3 25,2 30,9 31,3 35,8 42,8
Dati AHRI
Cooling capacity (AHRI 550/590) kW 6 61,3 69,1 80,7 88,1 95,5
Total power input (AHRI 550/590) kW 6 12,9 14,3 16,2 18,3 20,4
COP
R
6 4,75 4,83 4,98 4,81 4,68
IPLV 6 5,24 5,23 5,20 5,12 5,04
The Product is compliant with the ErP (Energy Related Products) European Directive. It includes the Commission delegated Regulation (EU) No 811/2013 (rated heat output ≤ 70 kW at
specified reference conditions) and the Commission delegated Regulation (EU) No 813/2013 (rated heat output ≤ 400 kW at specified reference conditions).
Contains fluorinated greenhouse gases’(GWP 675).
1. Entering/leaving water temperature user side 23/18 °C, Entering external exchanger air temperature 35 °C.
2. EER (EN 14511:2018) cooling performance coecient. Ratio between delivered coolimg capacitu and power input in compliance with EN 14511:2018.
3. User side entering/leaving water temperature 12/7 °C, external exchanger entering air 35 °C.
4. Data referred to unit operation with inverter frequency optimized for this application..
5. Data calculated according to the EN 14825:2016 Regulation.
6. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water temperature = 6,7 °C. Water flow-rate 0,043 l/s per kW. Entering external
exchanger air temperature 35°C. Evaporator fouling factor = 0.18 x 10^(-4) m
2
K/W.
