USER menu - DOPPIO SETPOINT
Press ▲▼ to ENABLE or DISABLE.
Abilitare il doppio setpoint
Press ◄ ► to select the setpoint mode
Press ▲▼ to adjust the parameters
The 2nd setpoint is activated only if the “temp-switch” input on
the terminal block XT2 is closed
USER menu - TEMPERATURE COMPENSATION
The water temperature is adjusted based on the outdoor tempe-
rature T4.
COOLING
The following parameters can be adjusted:
T4_cool_1 (25~30ºC)
T4_cool_2 (30~40ºC)
