CLIVET WSAT-YSI - Page 3

Controller addressing - MENU + ► 3 sec
16 unit max: master unit + 15 slave unit
UNIT 1 - MASTER 2 - Slave 3 - Slave 16 - Slave
Addr. controllo 0 1 2 15
15 unit max: controller MASTER + 15 unit (1 master + 14 slave)
UNIT Controller master 1 - MASTER 2 - Slave 15 - Slave
Addr. controllo 0 1 2 15
Modular unit
Unit addressing - ENC4
UNIT 1 - MASTER 2 - Slave 3 - Slave 16 - Slave
Addr. 0 1 2 15
ENC4 0 1 2 F
