STATUSES DISPLAY
Press UP on the main sheet
Standby: unit address (88 to the left) + online number (88 to the right)On: frequency defrosting:
dFdF
0.xx
unit address
1.xx
unit size
2.xx
number of units
3.xx —
4.xx
Operation Mode (8: Off; 1: Cooling)
5.xx
Mode Setting (8: Off; 1: Cooling)
6.xx
Water setpoint Ts
7.xx Fan speed
8.xx T4: outside temperature
9.xx —
10.xx —
11.xx Taf2: exchanger outlet temperature, antifreeze protection
12.xx Tw: common outlet water temperature, after the last unit
t.xx Twi inlet water
14.xx
Two outlet water
15.xx
Tz total outlet water
16.xx —
17.xx
Discharge temp. 1
18.xx
Discharge temp. 2
19.xx
Radiation fin temperature 1
20.xx
Radiation fin temperature 2
21.xx —
22.xx Compressor current A
23.xx Compressor current B
24.xx —
25.xx
—
