1. Compressor enclosure
2. Quadro elettrico
3. Power input
4. Inlet water connection Victaulic 2"
5. Outlet water connection Victaulic 2"
6. Functional spaces
7. Electrical fan
8. Unit fixing holes
9. External exchanger
* Antivibration mounts position
Size 30.2 - 35.2 - 40.2
SIZE 30.2 35.2 40.2
Lenght mm 3221 3221 3221
Depth mm 1089 1089 1089
Height mm 1510 1510 1510
Operating weight kg 680 680 680
Shipping weight kg 650 650 650
Operating weight with storage kg 1030 1030 1030
Shipping weight with storage kg 725 725 725
The presence of optional accessories may result in a substantial variation of the weights shown in the table.
DAANC0002_30.2-40.2 REV00
Data/Date 24/11/2020
