TRANSAXLE(TYPEG)Transaxle
20
TRANSAXLE
SeeGeneralWarningsonpage1-1.
TRANSAXLEREMOVAL
1.Disconnectthebatterycablesanddischargethecontrollerasinstructed.SeeWARNINGS“Toavoid
unintentionallystarting...”and“Afterdisconnectingthebatteries,wait90seconds...”inGeneral
Warningsonpage1-1.
2.Placechocksatthefrontwheelsandslightlyloosenlugnutsonbothrearwheels.SeeWARNING“Liftonlyone
end...”inGeneralWarningsonpage1-1.
3.Placeaoorjackunderthetransaxleandraisetherearofthevehicle.Positionjackstandsunderthealuminum
framerailsforwardofthespringmount.Lowerthevehicletoletthejackstandssupportthevehicle(Figure20-6,
Page20-5).SeeWARNING“Liftonlyoneendofthevehicle...”inGeneralWarningsonpage1-1.
4.Removetherearwheels,thenthreadonelugnutontoastudoneachrearhub.Thiswillkeepthebrakedrums
onthehubs.
5.Removethebowtiepins(1)andbrakecableclevispins(3).Usetool(CCIP/N102555501)tocompresstangson
cableendandremovecableendfrombracket(4)(Figure20-7,Page20-5).
1
2
3
4
682
Figure20-6VehicleSupportedonJackStands
651
Figure20-7BrakeCable
6.Disconnecttheshockabsorbersfromtheirlowermounts(Figure20-8,Page20-6).
7.Disconnectthefourmotorwires.Usetwowrenchestopreventthepostfromturning.
8.Withaoorjacksupportingthetransaxle,removelowerspringshacklenutsandbolts.Positionshacklesso
theyareclearofsprings(Figure20-9,Page20-6).
9.Ifachainhoistwasusedtoraisethevehicle,liftthevehiclehighenoughtopermiteasyaccessandclearance
forremovalofthemotor.Ifaoorjackwasusedtoraisethevehicle,lowerthetransaxleenoughtopermit
easyaccessandclearanceforremovalofthemotor.
10.Removethethreemotormountingbolts(1)(Figure20-11,Page20-7)andthemotorpositioningbolt(EJ4–4001
and5BC59JBS6390motorsonly)(Figure20-12,Page20-7),securingthemotortothetransaxle.Seefollowing
CAUTION.
2008ElectricPrecedentMaintenanceandServiceManualPage20-5
