Club Car Precedent Maintenance And Service Manual

17
TransaxleRemovalELECTRICVEHICLE-TRANSAXLE
767
Figure17-8DisconnectShocks
2700
Figure17-9Shackles
12.Ifaoorjackwasused,pulloorjackfrombeneaththetransaxleandallowthespringstorestontheoor.
13.RemovetheU-boltsattachingthetransaxletotheleafsprings(Figure17-10,Page17-6).
14.Carefullylifteachendofthetransaxleoffitspositioningpin(ontheleafspring)andslidethetransaxletotherear
andoutofthevehicle.
15.Drainthelubricantfromthetransaxleandremovetheaxleshafts.SeeAxleShaftandOilSealRemovalon
page17-1.SeefollowingNOTE.
NOTE:Recycleordisposeofusedoilorlubricantinaccordancewithlocal,state,andfederalregulations.
16.Removethebrakeassembliesifrequired.SeeBrakeClusterRemovalonpage6-13.
1
2
1.Precedent2.Villager4
1
2
3
4
769
Figure17-10LeafSprings
770
Figure17-11MotorMountingBolts
Page17-62020Precedent,Villager2and4MaintenanceandServiceManual
