GB
33
• If foreign objects are drawn into the cutting
mechanism or the product makes unusual
noises or vibrates abnormally, immediately
stop the motor and allow the product to come
to a standstill.
• Never put hands, other parts of the body or
clothing into the feed hopper, ejection chan-
nel or in the vicinity of other moving parts.
• Always remove the cut material from the ejec-
tion zone before it piles up. In this way, you
avoid blocking the product or allowing cut mate-
rial to enter the feed hopper opening via kick-
back. This may lead to accidents.
• In the vicinity of 15 m around the cutting area
there should be no people or animals as they
may be hurt by flying objects.
• Do not operate the product on paved or
cemented areas. The cut material may rebound
and cause injuries.
• Do not tip, lift or transport the product when
the motor is running.
• Do not reach into the feed hopper or ejection
opening during operation. After switching off,
the product runs for approximately 5 seconds.
• Ensure that the On/Off switch is set to Off
when you put the plug into the socket.
• Make sure you are outside of the ejection
zone when working with the product. Never
stand higher than the product when feeding in
material.
• The ventilation slots may not be covered by
the collection container or by chipped mate-
rial.
Product overview
Figure 1 – Page 3
1. Feed hopper
2. Push bar
3. Handle
4. Reset button
5. Directional switch
6. On/Off switch
7. Connection socket
8. Clearance adjustment screw
9. Ejection opening
10. Frame
11. Axle
12. Wheels
13. Bracket for collection bag
14. Collection bag
Unpacking and assembly
Unpack the product and make sure all of the pieces
are there.
Scope of delivery
• Shredder
• Frame bars
• Axle
• Wheels (2x)
• Push bar
• Operating instructions
• Collection bag
Assembly
Assembling the undercarriage
Figure 2 – Page 4
– Push the axis (11) through the frame bars (10).
– Undo the wheel cap (15) from the wheels (12)
and secure to the ends of the axis (11) using
nuts (16) and washers (17).
– Attach the wheel caps (15) back onto the
wheels (12).
Inserting the undercarriage
Figure 3 – Page 4
– Place the undercarriage (10) on screws on the
lower section of the housing.
– Use suitable tools to secure the nuts (18).
Use the collection bag
Figure 1 – Page 3
– Clamp the holding loops of the collection
bag (14) in the holders (13) on both sides of the
product.
Operation
Check before starting the device!
Check to make sure the product is in a safe operating
condition:
– Check to make sure that the feed hopper is
empty.
– Make sure that all parts sit tightly.
DANGER! Risk of injury! The product
must be assembled on an even, flat and
solid surface. You will need at least two
people to assemble the product.
DANGER! Risk of injury! The product
may only be put into operation if there are
no faults can be found. If a part is defec-
tive, it must be replaced before the product
is used again.
214389_Schredder_Elektrisch.book Seite 33 Dienstag, 13. April 2021 9:23 09
