Notable Terminology
Refers to the block of components responsible for cutting that is anchored to the gantry—includes the
spindle, drill block, and dust hood (upgrade). Whenever there is a mention of machine movement, it refers to
this block (and not to be confused with the router, since the router, after all, is stationary during operations).
Refers to the entire Raptor XPR, including its controller/control cart.
Router
Machine
Location Pins
Control Cabinet
The “machine”
Dual layer, high
flow phenolic
vacuum table
Loading
Wheels
Helical Rack
& Pinion Rail
System
