CNC UC100 User Manual

V2.121
Bug fixes in this release:
1.)
G28.1 stuck the program execution if executed from G-code program. Bug fixed.
2.)
Jog function was not working on B and C axis. Bug fixed
3.)
In plasma mode the index prescale value was not shown in the plugin. Bug fixed.
Update in the automatic installer:
1.) Windows 8 x86 and x64 support was added, now the installer works on Windows 8 OP systems.
V2.123
Functions were missing in previous version and were added in this release:
1.) M10P1/M11P1 and E0P1/M1P1 fast output codes were implemented.
(Useful function for example for laser machines.)
Bug fixes in this release:
1.)
Modifications in the handling of G28.1 and G30 codes.
2.)
Modifications in G04 delay code to work more precisely in the milliseconds range. Note: the minimal
executable setting is 200msec, lower value parameters will execute as 200msec.
V2.124
Bug fixes in this release:
1.) The spindle output PWM produced a very short extra pulse when Mach3 going into E-stop mode. This pulse
was removed. Bug fixed.
2.) Plugin default jog mode on installation was MPG mode which caused doubts for some customers, we
changed the default jog mode now to continous mode in this plugin.
This was not a bug though, just a comfort issue.
V2.125
New installer and common drivers for UC100, UCR200 and UC300 was released.
V2.127
Bug fixes in this release:
1.)
It was possible to switch the spindle on when e-stopped with a short pulse going out on the spindle output
signal. This bug was fixed.
V2.128
Functions were missing in previous version and were added in this release:
1.) Added jog to motor tuning window. Now after entering the motor tuning window and changing the motor
parameters and after pressing the Apply button the new settings can be tested with the keyboard jog keys
without leaving the motor tuning window. This makes axis calibration faster and more comfortable.
2.)
Errors indication on the UC100 I/O monitor window's bottom side.
Bug fixes in this release:
1.)
Index prescaler only appeared if loading the default (Mach3mill.xml), the prescaler now appears with all
Mach3 xml's. Bug fixed.
2.)
At the end of the G-code program executions if the jogging was executed, the G-code line pointer was
jumped to random line locations. Bug fixed.
3.)
Probing was working with errors in some cases. Bug fixed.
4.)
SetMachZero() function was not working correctly, it did not zero the axis. Bug fixed.
5.)
Issue with Master/Slave homing if set to home separately was not working. Bug fixed.
Notes: This plugin version was not officially released, the V2.129 plugin was released after the V2.127.
V2.129
Bug fixes in this release:
1.)
Program execution stopped in some cases if a slave axis was setup. Bug fixed.
2.)
The THC inputs for plasma were not working via software control like via brains. Bug fixed.
V2.133
Bug fixes in this release:
1.)
In specific circumstances the position DRO's stopped to update. Bug fixed.
2.)
E-stop event in Mach3 to charge pump output release got better syncronisation.
3.)
Grammatical text error fixed on the plugin update screen.
Having a problem, found a bug? Inform us and we will fix it quickly!
