CNC4PC C10 - Connecting PNP Sensors

User’s Manual Page 10
10.4 Connecting PNP sensors.
Fig. 7 Wiring diagram to connect PNP proximity sensors
Connecting PNP proximity sensor with the C25
R Value (12V)
R Value (24V)
Approx. 10KΩ
Approx. 25KΩ
