5. Care and maintenance
Changing the saw blade
1. Open theupper and lower blade pulley wheel covers.
2. Remove thescrew from theend of
thesaw blade.
3. Turn theblade tension knob (4)
anticlockwise until theblade comes loose.
4. First put on apair of work gloves and then carefully remove theblade from thesaw, theteeth are very sharp.
5. Fit thenew blade in reverse order making sure that theteeth are pointing down towards thetable.
6. Tension theblade as directed in “Setting up theblade tension and tracking”.
7. If necessary, adjust theblade guides as directed in “Setting up theblade guides”.
Changing the speed/drive belt
1. Remove theblade; refer to “Changing thesaw blade”.
2. The motor is fastened by two bolts on theback of thesaw.
3. Undo thetwo bolts so themotor can be
moved and thebelt loosened.
4. The blade speed can be changed by moving
thedrive belt between drive pulley wheels.
The outer pulley wheels (as in fig.) move theblade
at 660 m/min and theinner wheels (see arrows)
move theblade at 960 m/min.
