3. Assembly
Note! Make sure that theband saw is disconnected from themains before assembly.
Fitting the table and rip fence
3. Loosen thetable locking wing nut (17) and adjust it so that it is at aright angle to theblade.
Tighten thewing nut again.
Setting up the table
1. Loosen thescrew that secures thepointer (16) and set thepointer to 0°.
2. Place aset square against thetable and blade.
1. Fit thetable onto thetrunnion (15) and secure it
using thebolt and wing nut (17).
2. Fit therip fence (2) and its rail onto thetable.
