CO/Tech JFB10-UK - Setting Up Blade Tension and Tracking

7
ENGLISH
12
4
4. Slowly rotate theupper pulley by hand to make sure that theblade is centred on both of theblade pulley wheels.
5. If adjustment is necessary, loosen thewing nut on thetracking knob (12) and move theknob in or out until
theblade runs true.
1. Open theupper and lower pulley
wheel covers.
2. Adjust theblade tension using thetension
knob (4). Turn theknob clockwise to
increase thetension, anticlockwise to
decrease thetension.
3. The saw blade is correctly tensioned if
it can be moved approximately 10 mm
sideways with moderate hand pressure.
Setting up the blade tension and tracking
