InstrumentOverview




LCDDisplay
TheLiquidCrystalDisplay(LCD)showsthefollowingfeatures:
 CO2concentrationlevelinparts‐per‐million(ppm)for1%and5%models
 CO2concentrationlevelinpercentageformat(##.##%)forallothermodels
 LoggingON/OFF
 Percentageoffreememory


Display
ShowsCO2
concentration
level,data
loggingandfree
memoryspace.
PowerJack
Connectincluded
powersupply.
PowerSwitch
Turnsthemeter
ON/OFF.
LOGSwitch
Turnslogging&
pumpON/OFF.
Inlet
Outlet
RubberBoot(x2)
Protectsmeter
andimprovesgrip.
BarbFitting(x2)

USBConnector(covered)
ConnectincludedUSBcable
tocommunicatewithunit.
USBConnector
(coverremoved)
