3
1. Introduction
The tracker working based on the GSM/GPRS/LBS/AGPS network and GPS
satellite positioning system, which set multiple functions of security, positioning,
monitoring surveillance, emergency alarms and tracking in its entirety. It can
track and monitor remote target by SMS or internet.
2. Hardware Description
① GSM Antenna jack ⑥ USB jack
② SIM card slot ⑦ Power wire connection jack
③ SD card slot ⑧ Turn ON/OFF switch
④ SIM card slot Pop-up switch ⑨ Power/GSM/GPS LED indicator
⑤.GPS Antenna jack ⑩. Microphone jack
⑾ Remote control receiver antenna(TK103B Optional)
