COBHAM FliteLine CVC-151 User Manual

CVC-151
VHF Communication System
Installation Manual
Section 1 - General Information
150-048100 Rev. H
Page 12
Table 1-2. CVC-151 Specifications (cont'd)
CHANNEL SPACING:
8.33 kHz Fixed, 25 kHz Fixed, 8.33/25 kHz Switchable
RF POWER OUTPUT:
20 Watts nominal, 16 Watts minimum over temperature
DUTY CYCLE:
1 min on 4 min off, continuous at reduced power without damage to
unit.
HARMONIC CONTENT:
60 dB down from carrier minimum
TX SPURIOUS OUTPUT:
80 dB down from carrier minimum
MODULATION
CAPABILITY:
85% minimum with 95% limiting @ 1 kHz
MODULATION FIDELITY:
4 dB maximum variation in modulation percentage,
350 Hz to 2,500 Hz
RECEIVER SENSITIVITY:
2.0 V maximum for 6 dB (S+N)/N (hard)
NOISE LEVEL:
30 dB minimum (S+N)/N ratio for 100 V
SELECTIVITY:
`
25 kHz MODE:
-6 dB maximum at  10 Hz, -60 dB minimum  25 Hz
8.33 kHz MODE:
-6 dB maximum at  3.55 Hz, -60 dB minimum  5.05 Hz
AGC RANGE:
3 dB maximum audio variation, 5 to 10,000 V
AUDIO OUTPUT:
10 mW into 600 ohm load,
20 mW into 600 ohm load,
40 mW into 600 ohm load
As defined by the part number:  5% tolerance
AUDIO RESPONSE:
3 dB maximum variation, 350 Hz to 2,500 Hz
40 dB minimum attenuation at 4,000 Hz
AUDIO DISTORTION:
Receive
5% max. at rated output (85% modulation at 100-10,000 V)
Transmit
10% maximum (85% modulation), 350 Hz to 2,500 Hz
AUDIO INPUT:
Dynamic or carbon microphone, 0.250 V to 2.5 V operation range
SIDETONE OUTPUT:
10 mW into 600 ohms (85% modulation)
20 mW into 600 ohms (85% modulation)
40 mW into 600 ohms (85% modulation)
As defined by the part number:  5% tolerance
SIDETONE FIDELITY:
3 dB maximum variation, 350 Hz to 2,500 Hz
FREQUENCY CONTROL:
Gray Code/ARINC 429
ARINC Label 030, for 25 kHz tuning
ARINC Label 047, for 8.33 kHz tuning
