COBHAM FliteLine CVC-151 User Manual

CVC-151
VHF Communication System
Installation Manual
Section 1 - General Information
150-048100 Rev. H
Page 11
1.5 TECHNICAL SPECIFICATIONS
Table 1-2 CVC-151 Specifications
CERTIFICATION:
Transmitter
TSO-C169, DO-186A Class 3 & 5, and EUROCAE ED-23B, DO-160E
ENV CAT.
[(F2)Z]AAB[S(M)R(B)(B1)U(G)]EWXXXXZZAZCC[FY]H[A3E33]XXAX
Receiver
TSO-C169, DO-186A Class C & E, and EUROCAE ED-23B, DO-160E
ENV. CAT.
[(F2)Z]AAB[S(M)R(B)(B1)U(G)]EWXXXXZZAZCC[FY]H[A3E33]XXAX
Intermodulation
Paragraph 2.2.10 (EUROCAE ED-23B, Section 3.1.10)
Desensitization
Paragraph 2.2.11 (EUROCAE ED-23B, Section 3.1.11)
FCC IDENTIFICATION:
FRWCVC-151
TEMPERATURE RANGE:
Operational
-55 C to +70 C (-67 F to +158 F)
Storage
-55 C to +85 C (-67 F to +185 F)
COOLING:
Free air circulation
ALTITUDE:
55,000 feet (16,764 meters)
WEIGHT (Standard Configuration) *:
CVC-151 Unit
4.2 lbs. (1.9 kg) +/- 0.2 lbs (.09 kg)
Single mounting tray
0.85 lbs. (0.39 kg) +/- 0.2 lbs (.09 kg)
Dual mounting tray
2.16 lbs. (.98 kg) +/- 0.2 lbs (.09 kg)
OVERALL DIMENSIONS (Standard Configuration) *:
Height:
4.00 inches maximum (101.60 mm)
Width:
2.40 inches maximum (60.96 mm)
Length:
13.30 inches maximum (337.82 mm)
*Note:
See Figures 2-2 to 2-4 for weights and dimensions of CVC-151 in mounting tray and with
available options.
INPUT POWER REQUIREMENTS:
Receive (NORM)
22 to 33 VDC, 0.8 Amps @ 22 V
27.5 VDC, 0.8 Amps typical
(EMER)
18.0 VDC, 1.1 Amperes typical
Transmit (NORM)
22 to 33 VDC, 7.1 Amps @ 22 V
27.5 VDC, 5.4 Amps typical
(EMER)
18.0 VDC, 8.9 Amperes typical
FREQUENCY RANGE:
118.000 MHz to 136.975 MHz
118.000 MHz to 151.975 MHz optional
FREQUENCY STABILITY:
± 2.5 PPM
Continues…….
