Chapter 6: Service and maintenance

86 Available parts

6.5 Available parts

6.5.1 Cables and connectors

Part number Item

406100-930 Mini/Micro NMEA 2000 T-Connector

406100-931 Micro NMEA 2000 T-Connector

406100-932 Inline Micro termination Connector

406100-933 Male Mini NMEA 2000 Field Connector

406100-934 Male Micro NMEA 2000 Field Connector

406100-940 6 m NMEA 2000 Micro Device Cable

406100-941 20 m NMEA 2000 Micro Device Cable

406100-943 6 m NMEA 2000 Power Cable

406100-944 30 m NMEA 2000 Mini Device Cable

406100-945 50 m NMEA 2000 Mini Device Cable

406208A SAILOR 6208 Control Unit Connection Box

Table 17: Cables and connectors, part numbers
