Chapter 1: Introduction
System components 7
11111
Introduction
SAILOR 6285 GNSS Antenna - Active
The SAILOR 6285 GNSS Antenna - Active is a robust, sealed and waterproof
GPS antenna (classified IPx6 & IPx8).
SAILOR 6004 Control panel
The SAILOR 6004 Control panel is the user interface for the SAILOR 6282
AIS Transponder. Through the touch panel you access all settings that can
be changed by the user. Alarms and notifications are shown in the display.
The SAILOR 6004 Control panel has a buzzer for alarm tones. The display
supports night mode. The AIS application is loaded into the SAILOR 6004
Control Panel during installation.
Figure 3: SAILOR 6282 AIS Transponder
Figure 4: SAILOR 6285 GNSS Antenna - Active
