Appendix A: Specifications
66 SAILOR 6285 GNSS Antenna - Active
SAILOR 6285 GNSS Antenna - Active
Item Specification
Dimensions Ø: 91 mm, H: 77.5 mm
Weight 0.15 kg
Mounting Bracket mount on pipe, thread 1” x 14 TPI
Equipment class Exposed, according to IEC 60945
Antenna type Active patch antenna
Frequency 1570 to 1608 MHz
Impedance Nominal 50 Ohm
Polarization Circular right-hand
Coverage Hemispherical
Selectivity 45 dB down at center ±25 MHz
Gain 28 dB
Supply voltage 5 ±1 VDC
Current consumption Approx. 30 mA
Connector TNC female
Cable RG214 recommended
Operating temperature -40 °C to +55 °C
Storage temperature -40 °C to +70 °C
Table 17: SAILOR 6285 GNSS Antenna - Active specifications
