COBHAM Sailor 6390 Assembly Instruction

406390A-00500 Sailor 6390 Navtex Receiver
406390A Navtex Receiver
97-138962-A Assembly Instruction
22 May 2013 Page 1 of 9
1. Overview
This instruction describes in pictures and words, how to assemble Sailor 6390 Navtex Receiver.
2. Tooling list
#T1: El-screwdriver 0.8 Nm ± 0.1Nm. Torx 10 and 20. Rotational speed: 600 ±50 rpm.
#T2: El-screwdriver 1.15 Nm ± 0.1Nm. Special nut tool for TNC connector.
3. Extra materials
#M1: Type label part no. 48-124727.
4. Enclose
#E1:
5. Reference documents
#R1: Test Instruction, Navtex Unit Test part no. 96-139310.
6. General guidelines
Assembly must take place in an antistatic environment. All soldering irons must be connected to earth
(GND) and persons handling PCBs and components must use antistatic bracelets or similar
protection.
All assembly has to follow the standard IPC-A-610D.
Important:
This instruction is the basis for all local instructions. All pictures and illustrations must be reproduced in
colours to show the details.
