COBHAM Sailor 6390 Assembly Instruction

406390A-00500 Sailor 6390 Navtex Receiver
406390A Navtex Receiver
97-138962-A Assembly Instruction
22 May 2013 Page 6 of 9
7.4. Navtex Unit Test.
The Navtex receiver is now ready for unit test.
#R1: Test Instruction, Navtex Unit Test part no.
96-139310.
Figure 13
7.5. Cover assembly.
Place Light Guide part no. 41-135847 in Cover For
Navtex Receiver part no. 87-136721.
Figure 14
Mount light guide with Screw part no. 51-204304-038.
#T1: El-screwdriver 0.8 Nm ± 0.1 Nm Torx 10.
Rotational speed: 600 ±50 rpm.
Figure 15
